| 그림 | 모델 | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Master SD 20-4 | 20 | 1.6 | 2 | 4 | 220~240 | 50/60 | 25 | 130 | G1 |
|
Master SD 20-7 | 20 | 2.2 | 4 | 6 | 220~240 | 50/60 | 52 | 130 | G1 |
|
Master SD 25-4 | 25 | 1.8 | 2 | 4 | 220~240 | 50/60 | 25 | 130/180 | G1 1/2 |
|
Master SD 25-5 | 20 | 2 | 2.7 | 5 | 220~240 | 50/60 | 33 | 130/180 | G1 1/2 |
|
Master SD 32-4 | 32 | 1.8 | 2 | 4 | 220~240 | 50/60 | 25 | 180 | G2 |
 |
Basic 40-16SF | 40 | 8 | 15 | 18 | 380 | 50 | 1000 | 250 | DN40 |
 |
Basic T40-12F | 40 | 8 | 10 | 14 | 220~240 | 50 | 700 | 304 | Flanged |
 |
PH-101 | 40 | 5 | 3 | 5 | 220 | 50 | 200 | 238 | G1 1/2 |
