| 그림 | 모델 | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
PH-123 | 50 | 8 | 3 | 5 | 220 | 50 | 220 | 275 | G2 |
 |
PH-251 | 65 | 11 | 4 | 7.5 | 220 | 50 | 410 | 290 | G2 1/2 |
 |
PH-254 | 40 | 3 | 10 | 15 | 220 | 50 | 330 | 270 | G1 1/2 |
 |
PH-402 | 80 | 11 | 10 | 16 | 220 | 50 | 850 | 335 | G3 |
|
PH-402Q | 80 | 11 | 10 | 16 | 380 | 50 | 850 | 335 | G3 |
|
PH-403 | 50 | 8 | 16 | 20 | 220 | 50 | 1000 | 335 | G2 |
|
PH-403Q | 50 | 8 | 16 | 20 | 380 | 60 | 1000 | 335 | G2 |
 |
PH-1501Q | 50 | 16 | 15 | 25 | 380 | 50 | 1750 | 428 | G2 |
