| 그림 | 모델 | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
PUN-200L | 25 | 2 | 10 | 15 | 220 | 50 | 320 | 253 | G1 |
 |
PUN-400 | 32 | 3.0 | 15 | 21 | 220 | 50 | 680 | 283 | G1 1/4 |
|
PUN-401 | 25 | 3 | 15 | 21 | 220 | 50 | 660 | 283 | G1 |
|
PUN-751 | 32 | 5 | 20 | 30 | 220 | 50 | 1250 | 315 | G1 1/4 |
 |
PUN-1100 | 50 | 13 | 15 | 23 | 220 | 50 | 1500 | 385 | G2 |
 |
PH-041 | 25 | 2 | 2.5 | 3.5 | 220 | 50/60 | 90 | 216 | G1 |
 |
PH-042 | 32 | 2 | 2.5 | 3.5 | 220 | 50/60 | 90 | 216 | G1 1/4 |
 |
PH-101 | 40 | 5 | 3 | 5 | 220 | 50 | 200 | 238 | G1 1/2 |
