| 그림 | 모델 | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 80-12SF | 80 | 28 | 7.5 | 12 | 380 | 50 | 1300 | 360 | DN80 |
 |
Basic S 20-4S | 20 | / | / | 4 | 230 | 50 | 50/40/30 | 130 | G1 |
 |
Basic S 25-4S | 25 | / | / | 4 | 230 | 50 | 50/40/30 | 130/180 | G1 1/2 |
 |
Basic S 32-4S | 32 | / | / | 4 | 230 | 50 | 50/40/30 | 180 | G2 |
 |
Basic S 20-5S | 20 | / | / | 5 | 230 | 50 | 65/50/40 | 130 | G1 |
 |
Basic S 25-5S | 25 | / | / | 5 | 230 | 50 | 65/50/40 | 130/180 | G1 1/2 |
 |
Basic S 32-5S | 32 | / | / | 5 | 230 | 50 | 65/50/40 | 180 | G2 |
 |
Basic S 20-6S | 20 | / | / | 6 | 230 | 50 | 70/60/50 | 130 | G1 |
 |
Basic S 25-6S | 25 | / | / | 6 | 230 | 50 | 70/60/50 | 130/180 | G1 1/2 |
 |
Basic S 32-6S | 32 | / | / | 6 | 230 | 50 | 70/60/50 | 180 | G2 |
 |
Basic S 20-7S | 20 | / | / | 6.5 | 230 | 50 | 100/80/60 | 130 | G1 |
 |
Basic S 25-7S | 25 | / | / | 6.5 | 230 | 50 | 100/80/60 | 130/180 | G1 1/2 |
 |
Basic S 32-7S | 32 | / | / | 6.5 | 230 | 50 | 100/80/60 | 180 | G2 |
 |
Basic S 25-8S | 25 | / | / | 8 | 230 | 50 | 180/175/130 | 180 | G1 1/2 |
 |
Basic S 32-8S | 32 | / | / | 8 | 230 | 50 | 180/175/130 | 180 | G2 |
 |
Basic 40-6F | 40 | 12.5 | 4.5 | 6 | 230 | 50 | 500 | / | / |
 |
Basic T40-12F | 40 | 8 | 10 | 14 | 220~240 | 50 | 700 | 304 | Flanged |
 |
SPA15-12 Ⅲ | 15 | 0.3 | 11 | 12 | 24V | 50/60 | 45 | 90 | G 1/2 |
 |
PFB 06-22 pro | 25 | 6 | 22 | 28 | 220~240 | 50 | 700 | 260 | G1 |
 |
PFB 06-22 | 25 | 6 | 22 | 28 | 220 | 50 | 700 | 260 | G1 |
 |
PFM03-30 EC | 25 | 3.0 | 30 | 45 | 220 | 50 | 600 | 200 | G1 |
 |
PUN-200L | 25 | 2 | 10 | 15 | 220 | 50 | 320 | 253 | G1 |
 |
PUN-400 | 32 | 3.0 | 15 | 21 | 220 | 50 | 680 | 283 | G1 1/4 |
|
PUN-401 | 25 | 3 | 15 | 21 | 220 | 50 | 660 | 283 | G1 |
|
PUN-600 | 25 | 3 | 20 | 25 | 220 | 50 | 880 | 306 | G1 |
|
PUN-600 | 25 | 3 | 20 | 25 | 380 | 50 | 880 | 306 | G1 |
|
PUN-750 | 32 | 7 | 17.5 | 25 | 220 | 50 | 1100 | 322 | G1 1/4 |
|
PUN-750Q | 32 | 7 | 17.5 | 25 | 380 | 50 | 1100 | 322 | G1 1/4 |
|
PUN-751 | 32 | 5 | 20 | 30 | 220 | 50 | 1250 | 315 | G1 1/4 |
 |
PUN-1100 | 50 | 13 | 15 | 23 | 220 | 50 | 1500 | 385 | G2 |
